Capture OR Select from gallery and Crop Image on Android

Capture OR Select and Crop Image on Android


Hi Guys Today we are going to see very useful tutorial.
In One of my project I have requirement to capture or Select Image from gallery and Crop it for setting appropriate View on Profile.

Image select from gallery
Image capture from Camera


Here is Code for Doing that, In this code I included Everything in MainActivity.java If you need You can make more than one classes.

MainActivity.Java

package com.example.bestimageselectionwithcrop;

import java.io.File;
import java.util.ArrayList;
import java.util.List;

import android.app.Activity;
import android.app.AlertDialog;
import android.content.ActivityNotFoundException;
import android.content.ComponentName;
import android.content.Context;
import android.content.DialogInterface;
import android.content.Intent;
import android.content.pm.ResolveInfo;
import android.graphics.Bitmap;
import android.graphics.drawable.Drawable;
import android.net.Uri;
import android.os.Bundle;
import android.os.Environment;
import android.provider.MediaStore;
import android.view.LayoutInflater;
import android.view.View;
import android.view.ViewGroup;
import android.widget.ArrayAdapter;
import android.widget.Button;
import android.widget.ImageView;
import android.widget.TextView;
import android.widget.Toast;

public class MainActivity extends Activity {

       private Uri mImageCaptureUri;
       private ImageView mImageView;
       private AlertDialog dialog;

       private static final int PICK_FROM_CAMERA = 1;
       private static final int CROP_FROM_CAMERA = 2;
       private static final int PICK_FROM_FILE = 3;

       @Override
       protected void onCreate(Bundle savedInstanceState) {
              super.onCreate(savedInstanceState);
              setContentView(R.layout.activity_main);
              captureImageInitialization();

              Button button = (Button) findViewById(R.id.SelectImageBtn);
              mImageView = (ImageView) findViewById(R.id.ProfilePicIV);

              button.setOnClickListener(new View.OnClickListener() {
                     @Override
                     public void onClick(View v) {
                           dialog.show();
                     }
              });

       }

       private void captureImageInitialization() {
              /**
               * a selector dialog to display two image source options, from camera
               * ‘Take from camera’ and from existing files ‘Select from gallery’
               */
              final String[] items = new String[] { "Take from camera",
                           "Select from gallery" };
              ArrayAdapter<String> adapter = new ArrayAdapter<String>(this,
                           android.R.layout.select_dialog_item, items);
              AlertDialog.Builder builder = new AlertDialog.Builder(this);

              builder.setTitle("Select Image");
              builder.setAdapter(adapter, new DialogInterface.OnClickListener() {
                     public void onClick(DialogInterface dialog, int item) { // pick from
                                                                                                                     // camera
                           if (item == 0) {
                                  /**
                                   * To take a photo from camera, pass intent action
                                   * ‘MediaStore.ACTION_IMAGE_CAPTURE‘ to open the camera app.
                                   */
                                  Intent intent = new Intent(MediaStore.ACTION_IMAGE_CAPTURE);

                                  /**
                                   * Also specify the Uri to save the image on specified path
                                   * and file name. Note that this Uri variable also used by
                                   * gallery app to hold the selected image path.
                                   */
                                  mImageCaptureUri = Uri.fromFile(new File(Environment
                                                .getExternalStorageDirectory(), "tmp_avatar_"
                                                + String.valueOf(System.currentTimeMillis())
                                                + ".jpg"));

                                  intent.putExtra(android.provider.MediaStore.EXTRA_OUTPUT,
                                                mImageCaptureUri);

                                  try {
                                         intent.putExtra("return-data", true);

                                         startActivityForResult(intent, PICK_FROM_CAMERA);
                                  } catch (ActivityNotFoundException e) {
                                         e.printStackTrace();
                                  }
                           } else {
                                  // pick from file
                                  /**
                                   * To select an image from existing files, use
                                   * Intent.createChooser to open image chooser. Android will
                                   * automatically display a list of supported applications,
                                   * such as image gallery or file manager.
                                   */
                                  Intent intent = new Intent();

                                  intent.setType("image/*");
                                   intent.setAction(Intent.ACTION_GET_CONTENT);

                                  startActivityForResult(Intent.createChooser(intent,
                                                "Complete action using"), PICK_FROM_FILE);
                           }
                     }
              });

              dialog = builder.create();
       }

       public class CropOptionAdapter extends ArrayAdapter<CropOption> {
              private ArrayList<CropOption> mOptions;
              private LayoutInflater mInflater;

              public CropOptionAdapter(Context context, ArrayList<CropOption> options) {
                     super(context, R.layout.crop_selector, options);

                     mOptions = options;

                     mInflater = LayoutInflater.from(context);
              }

              @Override
              public View getView(int position, View convertView, ViewGroup group) {
                     if (convertView == null)
                           convertView = mInflater.inflate(R.layout.crop_selector, null);

                     CropOption item = mOptions.get(position);

                     if (item != null) {
                           ((ImageView) convertView.findViewById(R.id.iv_icon))
                                         .setImageDrawable(item.icon);
                           ((TextView) convertView.findViewById(R.id.tv_name))
                                         .setText(item.title);

                           return convertView;
                     }

                     return null;
              }
       }

       public class CropOption {
              public CharSequence title;
              public Drawable icon;
              public Intent appIntent;
       }

       @Override
       protected void onActivityResult(int requestCode, int resultCode, Intent data) {
              if (resultCode != RESULT_OK)
                     return;

              switch (requestCode) {
              case PICK_FROM_CAMERA:
                     /**
                      * After taking a picture, do the crop
                      */
                     doCrop();

                     break;

              case PICK_FROM_FILE:
                     /**
                      * After selecting image from files, save the selected path
                      */
                     mImageCaptureUri = data.getData();

                     doCrop();

                     break;

              case CROP_FROM_CAMERA:
                     Bundle extras = data.getExtras();
                     /**
                      * After cropping the image, get the bitmap of the cropped image and
                      * display it on imageview.
                      */
                     if (extras != null) {
                           Bitmap photo = extras.getParcelable("data");

                           mImageView.setImageBitmap(photo);
                     }

                     File f = new File(mImageCaptureUri.getPath());
                     /**
                      * Delete the temporary image
                      */
                     if (f.exists())
                           f.delete();

                     break;

              }
       }

       private void doCrop() {
              final ArrayList<CropOption> cropOptions = new ArrayList<CropOption>();
              /**
               * Open image crop app by starting an intent
               * ‘com.android.camera.action.CROP‘.
               */
              Intent intent = new Intent("com.android.camera.action.CROP");
              intent.setType("image/*");

              /**
               * Check if there is image cropper app installed.
               */
              List<ResolveInfo> list = getPackageManager().queryIntentActivities(
                           intent, 0);

              int size = list.size();

              /**
               * If there is no image cropper app, display warning message
               */
              if (size == 0) {

                     Toast.makeText(this, "Can not find image crop app",
                                  Toast.LENGTH_SHORT).show();

                     return;
              } else {
                     /**
                      * Specify the image path, crop dimension and scale
                      */
                     intent.setData(mImageCaptureUri);

                     intent.putExtra("outputX", 200);
                     intent.putExtra("outputY", 200);
                     intent.putExtra("aspectX", 1);
                     intent.putExtra("aspectY", 1);
                     intent.putExtra("scale", true);
                     intent.putExtra("return-data", true);
                     /**
                      * There is posibility when more than one image cropper app exist,
                      * so we have to check for it first. If there is only one app, open
                      * then app.
                      */

                     if (size == 1) {
                           Intent i = new Intent(intent);
                           ResolveInfo res = list.get(0);

                           i.setComponent(new ComponentName(res.activityInfo.packageName,
                                         res.activityInfo.name));

                           startActivityForResult(i, CROP_FROM_CAMERA);
                     } else {
                           /**
                            * If there are several app exist, create a custom chooser to
                            * let user selects the app.
                            */
                           for (ResolveInfo res : list) {
                                  final CropOption co = new CropOption();

                                  co.title = getPackageManager().getApplicationLabel(
                                                res.activityInfo.applicationInfo);
                                  co.icon = getPackageManager().getApplicationIcon(
                                                res.activityInfo.applicationInfo);
                                  co.appIntent = new Intent(intent);

                                  co.appIntent
                                                .setComponent(new ComponentName(
                                                              res.activityInfo.packageName,
                                                              res.activityInfo.name));

                                  cropOptions.add(co);
                           }

                           CropOptionAdapter adapter = new CropOptionAdapter(
                                         getApplicationContext(), cropOptions);

                           AlertDialog.Builder builder = new AlertDialog.Builder(this);
                           builder.setTitle("Choose Crop App");
                           builder.setAdapter(adapter,
                                         new DialogInterface.OnClickListener() {
                                                public void onClick(DialogInterface dialog, int item) {
                                                       startActivityForResult(
                                                                     cropOptions.get(item).appIntent,
                                                                     CROP_FROM_CAMERA);
                                                }
                                         });

                           builder.setOnCancelListener(new DialogInterface.OnCancelListener() {
                                  @Override
                                  public void onCancel(DialogInterface dialog) {

                                         if (mImageCaptureUri != null) {
                                                getContentResolver().delete(mImageCaptureUri, null,
                                                              null);
                                                mImageCaptureUri = null;
                                         }
                                  }
                           });

                           AlertDialog alert = builder.create();

                           alert.show();
                     }
              }
       }

}


 Now Create On more Layout as
crop_selector.xml

<?xml version="1.0" encoding="utf-8"?>
<LinearLayout
       xmlns:android="http://schemas.android.com/apk/res/android"
       android:layout_width="wrap_content"
       android:layout_height="wrap_content"
       android:padding="10dp"
>

       <ImageView
              android:id="@+id/iv_icon"
              android:layout_width="wrap_content"
              android:layout_height="wrap_content"/>

       <TextView
              android:id="@+id/tv_name"
              android:layout_width="wrap_content"
              android:layout_height="wrap_content"
              android:text=""/>
</LinearLayout>


and here is your activity_main.xml

<RelativeLayout xmlns:android="http://schemas.android.com/apk/res/android"
    xmlns:tools="http://schemas.android.com/tools"
    android:layout_width="match_parent"
    android:layout_height="match_parent"
    android:background="@drawable/bgimage"
    tools:context=".MainActivity" >

    <Button
        android:id="@+id/SelectImageBtn"
        android:layout_width="fill_parent"
        android:layout_height="wrap_content"
        android:layout_alignParentBottom="true"
        android:layout_centerHorizontal="true"
        android:layout_marginBottom="19dp"
        android:textColor="@android:color/white"
        android:textSize="24sp"
        android:layout_margin="20dp"
        android:background="@drawable/button_bg_pressed"
        android:text="Select Image" />

    <ImageView
        android:id="@+id/ProfilePicIV"
        android:layout_width="250dp"
        android:layout_height="250dp"
        android:layout_centerInParent="true"
        android:src="@drawable/ic_launcher" />

</RelativeLayout>

and there is No special changes in AndroidManifest.xml file

here you can download Complete Source Code Example

and you can follow original tutorial from here
